Post your Ryzen memory speeds!

you guys impressed?


erek said:
yah i am, think you can hit 2000 ?
Click to expand...
I was only messing with ya but I have not tried higher than 1933FCLK synced. Probably not possible but maybe with enough voltage anything is possible.
To tell the truth ,with proper DDR4 Ram timings no need to go higher as the results are the same with 1467 FCLK vs 1933FCLK. Even with 2000Mhz FCLK there will be no difference in performance for me. Higher Ryzen FCLK is a myth to me.

Tuned Ram AMD Ryzen Fabric Clock 1467Mhz (DDR4 2933Mhz) vs Fabric Clock 1933Mhz (DDR4 3866Mhz) in a couple games 1080p/1440p

  • Like
Reactions: erek
like this
gerardfraser said:
I was only messing with ya but I have not tried higher than 1933FCLK synced. Probably not possible but maybe with enough voltage anything is possible.
To tell the truth ,with proper DDR4 Ram timings no need to go higher as the results are the same with 1467 FCLK vs 1933FCLK. Even with 2000Mhz FCLK there will be no difference in performance for me. Higher Ryzen FCLK is a myth to me.

Tuned Ram AMD Ryzen Fabric Clock 1467Mhz (DDR4 2933Mhz) vs Fabric Clock 1933Mhz (DDR4 3866Mhz) in a couple games 1080p/1440p
Click to expand...


Damn, Cas 12 with 230 trfc! Both configurations were within 1-2% of each other. What voltage did you need in the memory?

Nightfire said:
Damn, Cas 12 with 230 trfc! Both configurations were within 1-2% of each other. What voltage did you need in the memory?
Click to expand...
All the settings are at end of video,voltages for memory were just give it enough voltage for stability without errors.
I have done CL 10 tRFC 220 at 1.38v stable,have not tried going lower,no point really. The Ram used was B-Die and could take 1.6v without problems.

Ryzen infinity fabric clock is a myth ,if you can set your ram up with tight timings.

AMD Ryzen Fabric Clock 1467Mhz (DDR4 2933Mhz) vs Fabric Clock 1933Mhz (DDR4 3866Mhz) Battlefield 5 and Grand Theft Auto V @1920x1080


AMD Ryzen Fabric Clock 1467Mhz (DDR4 2933Mhz) vs Fabric Clock 1933Mhz (DDR4 3866Mhz) Red Dead Redemption 2 and Sleeping Dogs @1920x1080

Last edited:
gerardfraser said:
Ryzen infinity fabric clock is a myth ,if you can set your ram up with tight timings...
Click to expand...

I don't have any experience with Ryzen 3k, but transfer rate / cas × trfc still looks to be the best starting point for performance. If you can run 0.9 or better, gaming performance will be great.

This may have been posted before but here is what even cheapo e-die manually tuned at 3000 mt/s with a 1500 b clock. In most cases it ran better than the stock 3800 stuff. Also, AIDA64 is definitely not an indicator for gaming performance.
Nice videos by the way. Looks like you put a lot of time in them. If you could make the text bigger from the overlays, they would be even better.


Yes I agree with you on the performance part cas × trfc .
Well I did not put much time in the video's or the Ram timings,just made sure they work stable ,but the OSD size could be bigger I guess but I can read it fine on 4K monitor.Maybe 1080P monitor you may not be able to see.I will have to check that out.
