Someone somewhere posted a guide on a simple mod on how to mount a 280 rad in the front of the R4 but I can't find it anymore. It involved lining up a 280 bracket and drilling 4 holes into the fan mount the front. Does someone have the link?

A

AudiTuner

Limp Gawd
Joined
Apr 18, 2010
Messages
329
Wow... there are some nice setups on here. Kind of makes me embarrassed to post mine (it's not nearly as neat).

Unknown-One

Unknown-One

[H]F Junkie
Joined
Mar 5, 2005
Messages
8,903
Cleaned up my R3 (including a full set of matching Arctic fans). I'm honestly shocked at the difference these made, especially the CPU fan. Dropped CPU temps about 10c across the board, with no increase in noise.

Graphics card is a GTX 780 with a modified ACX cooler. Again, the Arctic fans outperform the stock EVGA fans at lower noise levels :D





I wish there was a better way to power the sound card. Entire extra cable plugged into the modular PSU, just for that...

Last edited:
1

1337m0dd3r

[H]ard|Gawd
Joined
Jun 26, 2002
Messages
1,550
looks good man! how do you got your hd's rigged in there? thats my biggest issue with my case is the hd's transfer noise right into my desk like a speaker box.

Unknown-One

Unknown-One

[H]F Junkie
Joined
Mar 5, 2005
Messages
8,903
1337m0dd3r said:
looks good man! how do you got your hd's rigged in there? thats my biggest issue with my case is the hd's transfer noise right into my desk like a speaker box.
Click to expand...
They're suspended on bungee cord. I removed the drive rails and laced up bungee through the drive cage to create a double-X pattern.

Drives are installed by pulling the two X's apart and slipping the hard disk in-between. They're about as decoupled as they can possibly get.

I was honestly a bit surprised when I first fired up my machine with the drives mounted this way. I could put my hand on top of the case and it felt totally dead (no vibration at all). Seek noise was also totally gone. :D

M

Master [H]

2[H]4U
Joined
Mar 17, 2003
Messages
2,629
This is giving me some ideas on how to orient my cooling.
I got the Define XL R2, and I'm considering putting my H60 radiator out one of the top spots.

I knew it was on the larger side, but god-DAMN this thing is enormous! I'm waiting on a couple other parts to come in, but I'm excited to move my current rig over to this beast.

J

Justintoxicated

[H]F Junkie
Joined
Apr 10, 2002
Messages
14,455
Just finished my XL R2 build, you guys will love it. It has a custom loop with a slim 480 radiator for CPU and MB (recycled x48 chipset), and still has all the factory hard drive bays. Going to use it for my server and it is absolutely silent. Just need to get some software installed so I can start transferring off data from my old server and moving more drives over. Going to have to wait for a good time for pics though they are coming!

M

Master [H]

2[H]4U
Joined
Mar 17, 2003
Messages
2,629
I got my new PSU and DVDRW drive in, so that's what's in my XL R2.
The complaints about the PSU support and the grommets for the wiring are true. Kind of irritating until I got the PSU stands to stay until I had the PSU itself installed.

My ATX and 8-pin Aux wiring isn't long enough to run the length of the back, but not unsuprising as the connectors are behind the I/O panel with this particular motherboard, so It will probably just have to run alongside the mobo and then cut over.

M

Master [H]

2[H]4U
Joined
Mar 17, 2003
Messages
2,629
All installed. Had some creative wiring to do and with all the cabling behind the motherboard, I was afraid it would be a fight to get that side back on.
Nope!

No pics yet, but they'll be cell phone pics since I don't know where my wife's camera is.

F

Freemason115

Limp Gawd
Joined
Dec 26, 2002
Messages
368
Upon seeing this threads posts about this brand, I decided on getting the Fractal R4 windowed...I absolutely love the case.

Unknown-One

Unknown-One

[H]F Junkie
Joined
Mar 5, 2005
Messages
8,903
Anyone know of a good place to buy molex power adapters?

My sound card needs an FDD power connector, so I ended up running an entire extra cable from my modular PSU to support it... not exactly clean (especially with the limited room behind the motherboard tray on the R3).
I have spare SATA power connectors nearby, so an adapter like this would work:



Just needs to be a bit longer (and preferably pre-sleeved, in black). Can't find anyone selling such a thing, though.

Krenum

Krenum

[H]F Junkie
Joined
Apr 29, 2005
Messages
15,964
Unknown-One said:
Anyone know of a good place to buy molex power adapters?

My sound card needs an FDD power connector, so I ended up running an entire extra cable from my modular PSU to support it... not exactly clean (especially with the limited room behind the motherboard tray on the R3).
I have spare SATA power connectors nearby, so an adapter like this would work:



Just needs to be a bit longer (and preferably pre-sleeved, in black). Can't find anyone selling such a thing, though.
Click to expand...
Frozen CPU has a good selection and they are a pretty reputable site.

http://www.frozencpu.com/cat/l3/g2/c38/s428/list/p1/Cables-Cable_Adapters-Cable_Adapters-Page1.html

A

Adam

[H]ard|Gawd
Joined
Jan 9, 2003
Messages
1,592
Love these cases. I got one for my home server than got one for my regular PC as it was too loud with the fans:




D

Deleted member 23757

Guest
Freemason115 said:
Upon seeing this threads posts about this brand, I decided on getting the Fractal R4 windowed...I absolutely love the case.
Click to expand...
Agree! The design is so simple and understated and it realty stands out among all of the other case manufacturers and their odd shapes and designs.

G

Grimmy311

Limp Gawd
Joined
Oct 11, 2011
Messages
148
PerfectCr said:
Agree! The design is so simple and understated and it realty stands out among all of the other case manufacturers and their odd shapes and designs.
Click to expand...
Exactly my thoughts I LOVE their designs so simple, effective, and elegant.... Customer for life.

Z

zod96

Suspected BAD TRADER
Joined
Feb 23, 2008
Messages
2,709


Here is mine updated R4 going to replace that white fractal fan with 2 Corsair Red AF series ones..

N

Nemesis429

Weaksauce
Joined
Feb 27, 2012
Messages
97
My long awaited PC Build took me a few days to do what I wanted, this is pretty much my first PC Build that I've done proper, the USB cable from the Corsair cooler will be removed once I set it to green, I have yet to turn it on as my room is a mess :D.

Front:


Back:

Krenum

Krenum

[H]F Junkie
Joined
Apr 29, 2005
Messages
15,964
^ You should mount that Hard Drive and SSD in your 5.25 inch bay and take that HDD rack out.

A

Aaron_ATX

[H]ard|Gawd
Joined
Oct 15, 2003
Messages
1,804
Feel like I just won the golden yellow crash helmet award. It never occured to me to stash my ssd's on the back of my mobo try like that. Thanks for the pic.

Krenum

Krenum

[H]F Junkie
Joined
Apr 29, 2005
Messages
15,964
Aaron_ATX said:
Feel like I just won the golden yellow crash helmet award. It never occured to me to stash my ssd's on the back of my mobo try like that. Thanks for the pic.
Click to expand...
The annoying thing is, is that you have to take the motherboard out to get to the screws to add the SSD's to the back of the MB Tray.

N

Nemesis429

Weaksauce
Joined
Feb 27, 2012
Messages
97
Krenum said:
^ You should mount that Hard Drive and SSD in your 5.25 inch bay and take that HDD rack out.
Click to expand...
Here's why I kept it in (see below pic), it's because I added my WD Red 3TB's. I need to get a proper camera sometime soon, take some proper pictures, looks immense with the side panel on and the GPU/CPU lighten up in green especially with the side panel being smoked.


Z

zod96

Suspected BAD TRADER
Joined
Feb 23, 2008
Messages
2,709
OK finally got mine finished. Added 2 120MM Sharkoon Blade fans and a Msi 780 ti. Dead quiet pc and great temps....


C

Cozmo85

Limp Gawd
Joined
Jan 25, 2001
Messages
354
What 280mm aio coolers work in the r2 mini? And can you keep the optical drive?

T

ThatsAgood1jay

[H]ard|Gawd
Joined
Mar 21, 2006
Messages
1,025
Picked up a white R4 from MicroCenter last night. Got it all moved into tonight.

Went from a 2007 model Thermaltake to this, what a long way cases have come in 7 years!







I need to go back and do a bit of cable management, but I think it won't be much good until I get a modular psu, psu is same age as the case, and has about 9 molex connectors....of which I am using one, for the fan controller.

This case is so great, I have been on the fence about what new case to get for several months now, looking through this thread helped my decision alot!. Everything is running about 10c cooler than the thermaltake!

Also, apologies for the terrible photos, I am just completely inept with a camera.

Last edited:
M

Master [H]

2[H]4U
Joined
Mar 17, 2003
Messages
2,629
Finally, I have a pic of mine. It's at an angle and with my cellphone camera, but here it is.
