Dimensions (H x W x D): 15.75 x 9.85 x 11.42 in. (400 x 250 x 290 mm)
Doesn't have to have high SPL but should be SMALL
Studiophile BX5 Reference Monitors
The BX5s are the latest in the popular Studiophile series that delivers exceptional quality and professional sound at affordable prices. The BX5s offer 5.25-inch low-frequency drivers, 1-inch high-frequency drivers, and 75 watts of bi-amped near-field technology at a fraction of the cost of other monitors their size.
Monitors that adapt to your needs
Your monitors should be able to adapt to any changes in placement or work environment. Thats just what the BX5s do. Since a monitors bass response can change depending upon proximity to walls, the BX5s Acoustic Space control section allows you to optimize their performanceno matter whether you need to put them on stands, on a bookshelf or in the corners. You can also adjust the high-frequency response to compensate for reflective surfaces like glass. The presence control gives you an automatic mid-range boost for added flexibility. Theres even a variable low-frequency roll-off to optimize response at crossover points when adding a subwoofer like the Studiophile SP-8S.
The 1-inch natural silk high-frequency drivers employs a flush design and electronic time alignment with the low-frequency driver, resulting in controlled dispersion for superior three-dimensional imaging. The tooled rear Sub-Frequency Ports reduce low-frequency turbulence and optimize driver excursion for amazing bass in a small footprint
BX5 Specs
Type: Two-way near-field studio reference monitors
Low-frequency drivers: 5.25-inch magnetically shielded mineral-filled polypropylene cones, high-temperature tolerant voice coils and damped rubber surrounds
High-frequency drivers: 1-inch swivel-mounted natural silk domes incorporating magnetic shielding, ferrofluid and internal damping technologies
LF Amplifier Power: 38W (EIA RS-490 dynamic power)
HF Amplifier Power: 38W (EIA RS-490 dynamic power)
Crossovers: 4th-order Linkwitz Riley for smooth frequency response
Crossover Frequency: 3kHz
Low-frequency rolloff: 6th-order filter optimizes maximum driver excursion
Input Connectors: XLR balanced, TRS balanced/ unbalanced
Input Sensitivity: 85 mV pink noise input produces 90dBA output SPL at one meter with volume control at maximum
Input Impedance: 20k ohms balanced, 10K ohms unbalanced
Protection: RF interference, output current limiting, over temperature, transient on/off, subsonic filter, external main fuse
S/N Ratio: > 100dB below full output, A weighted
Frequency Response: 56Hz - 20kHz
Power indicator: Power on/off indicator on front panel
Power Requirements: 115V/~60Hz or 230V/~50Hz (selectable); power via detachable 3-conductor line cord
Dimension: 9.85 in. (h) x 6.54 in. (w) x 7.88 in. (d)
Weight: 11 lbs./unit (without packing)
Audio Inputs:Originally posted by agentzero9
Excuse the ignorance but how do you plug those speakers in? On the back there are no wire inputs.
Originally posted by agentzero9
Excuse the ignorance but how do you plug those speakers in? On the back there are no wire inputs.
Monitors are used mainly in studios for near-field listening. 1/4" jack is alot bigger than computer jack, 3.5mm, typically used in studios also.Originally posted by agentzero9
So these "monitor" type speakers are made with computers in mind?
I don't know any quality receivers or HTs that have headphone jacks to plug in speakers.
