Pictures Of Your Dually Rigs!

Originally posted by Anarchy
My second SLK800A arrived :)
Click to expand...
Nice clean looking rig! Don't you just love those S-ATA cables over the old IDE ones?

I'm a little concerned about the lack of exhaust fans immediately behind the CPUs...

That's not really a problem ... there's a 120m intake fan that pushes enough fresh air inside and theres another 92mm fan in the side panel blowing fresh air directly to the CPUs ...

but after all i'd say that i could rund that without case fans at all ... the CPUs (1800+)won't be stressed for the most of the time and get 1.4V (or less if possible) while clocked at 1666MHz / 2000+ ... i can't go higher without using the wire-in-socket trick ...

The part that really needs the fresh air is the FX5800@Ultra that is going to replace the GF2GTS :eek:

Originally posted by Anarchy
The part that really needs the fresh air is the FX5800@Ultra that is going to replace the GF2GTS :eek:
Click to expand...
Well, I guess the card will be cooled directly by the blowholes (TM)... :)

Anyway, I didn't mean to b!tch, just that the fans are not evident in your photo... ;) I guess with minimal cable blockage and good pair of blowholes (TM) over the heat sources, you can get away with it without an exhaust... :)

I made a post to this thread about 7 or 8 pages ago. Things have changed quite a bit sense then...

Whitebox:
Compaq Proliant 1600R w/ IMD
2x P2 450
1024M PC-100 ECC
Compaq Smart2DH RAID card
Onboard Netflex 3
5x 4.3G 10K RPM SCA drives in RAID 5
TDK 48x24x48 cdrw
2x WD 120JB in Enermax black removable racks RAID 0
Adic VLSDLT400 7 tape DLT 20/40 changer

Post:
Compaq Proliant 1600-66 w/ IMD
2x P2 300
512M EDO ECC
Compaq Smart2DH RAID card
Onboard Netflex 3
5x 2.1G 7200RPM SCA drives in RAID 5
Compaq 32X CDROM
Compaq DDS2 4/8G DAT on daily rotation

I'm working on replacing Whitebox, moving it to Post, and retireing post. Whitebox is running Win2k3. It runs DNS, DHCP, RIS, network wide backups, ADS, and a few other things. Post is, as the name implies, my mail server. It runs Windows 2000 Advanced server, and Exchange 2000, as well as a jump point web pages so I can preview and test them before I upload them.

Average CPU and Memory loads:
POST: 3% CPU/ 213M RAM
Whitebox: 4% CPU/288M RAM

I'll try to post pics when I can...
Nick

i have a few of them up and running and here they are.

the first one in my stable
dual xeon 450 (1meg) @ stock speeds and passive cooling!!! (note this is befor the scis and raid setups, no pics of current hd setup, but most of my pics are of systems in progressl)


and the next one one line is my dual AMD MP 2100+ (talk about a power jump)




and then came the Dual P3 1.4 Tully (had chips on hand)
P1010027 small.JPG


(had a few others that came and went, but no pics of them :()

newest monster cpu to the fold (and yes i fold)
see you can fit 12lb os cpu in to a 10 bl bag D.JPG


and ofcoures the single p4 ([email protected]) not in this case anymore in an antec mid tower just like the dual xeon above it.


I have a HP netserver LH PRO, Dual PPro runs linux sendmail and IMAP .

New Dually :D

I'm sellin the Tyan 860 + RAMBUS (germany only) and replace them with this :



Asus PC-DL 1.05
4*256MB Infineon PC333 - they all can do 220 MHz 2-3-2-* @ 2.8V on a NF7-S 2.0 :eek:
2*2.4GHz Xeon ... i hope to get 3GHz+

i'm using the Intel Boxed HSFs ... with silent YS Tech fans ... those original fans are plain annoying ...




Originally posted by Anarchy
i'm using the Intel Boxed HSFs ... with silent YS Tech fans ... those original fans are plain annoying ...
Click to expand...
Holy Batman, heatsinks and fans!! :eek: I know exactly what you mean by noisy fans... I didn't even bother to install any of mine, I went straight for the Swiftech MCX varients! ;)

I'm interested in that Tyan if you are selling it. PM me about it and a price.

I will be in Hamburg tommorow night and will be in Germany til the 7th of April.

I might be in germany before may, if you still have the old dual xeon/rambus board, send me a pm and we see what we can workout :D

and i need to get new hsf for my pc-dl it is a whiny little machine (not loud but annoying whine).

Dual 2400+ in Lian Li
48x burner
80GB 8mb cache
Asus A7M266-D
512mb PC2700
Aero 7's
400w Sparkle
Radeon 7500
Debian


The $600 duallie-




Dual Opteron 244
8GB PC2700 reg ECC ram
one has an Arima and the other has a Tyan K8S
Suse 9

The $6000 duallies-


one i built for a friend:




dual 2400+
2gb corsair DDR333

4x WD2500JB in 3ware RAID5

Originally posted by fubar569
all these make mine look like poopy...
anyone know of a heatsink that will fit on the Gigabyte ga-7dpxdw+ and cool 2 xp's clocked at [email protected]?
Click to expand...

A little OT, but i would like to know as well. I've got the same mobo, with a pair of xp2000's and TMC's and currently clocked at 1800, default volts. I need some better cooling. Case has 2 x 92mm fan's, one could be replaced with a 120 with a little work, and a psu with a 92mm fan in it.

I'll get a pic when my mum comes home from her holiday to Cairns, with my digi cam and digi camcorder.

Cheers

ToranaGuy

After livin on my desktop for 3 days the new sase finally arrived :D

"Final" Specs :

Coolermaster Case
Asus PC-DL
Dually Xeon 2.4GHz (OCed to 2.9GHz when i need the power)
4*256MB Infineon PC333
Enhance EPS12V PSU 460W
Albarton Ti4600
Silicon Image PATA RAID Controller
IBM 180GXP 120GB 8MB (OS, Apps, Games, Temp)
2*Samsung 160GB 2MB (RAID1 - Storage)
Compaq CD-ROM (to be replaced with DVD Burner)

... and soon i'll add a blue 4*20 LCD :D






Well, I bought an opteron. Here's what I have atm...

Board: Tyan K8W
CPU: Opteron 240 (I can always upgrade, right?)
Drives: 4x Fujitsu 36G 15,000 RPM U160 SCSI

Now the crown jewel:
Case: Lian-Li PC-78SCA (Picture is here --> http://scasp.webnow.biz/upload/a0000010/en_US/prd_380.jpg

Not sure what I wana do for a PS, wether to go w/ an RPS or a big std ps, as well as un-sure about what to do for RAID card and Video.

Thats it for now,
Nick

Pictures of the new web server.
Super Micro X5DPA-GG - Dual Xeon, E7501
Xeon 2,40 GHz, 512K, 533FSB with 1U Passive Heatsink
Super Micro 1U SC812 with 350W PSU
IPMI card for remote management
Hitachi, Deskstar 7K250 160GB 8MB
A pair of Kingston 512MB DDR DIMM PC2100 CL2.5 ECC REG LP
No real SMP machine, yet. Going to buy a second CPU soon, couldn't afford two from the beginning. It's running FreeBSD 4.9 and is working like a charm.

http://www.bumpa.net/~jage/files/media/images/phoo_building/

The server in use

Jage: Is this the IPMI card? I don't actually see it installed in any of the pics on your gallery.
questions:
How's it working for you?
What does it enable?
Where did you find a mini-PCI one?

ambit: Yes, you can see it here.
It is hidden under the IDE cables.
The remote management is working great.
I bought it from a Swedish Super micro dealer called mullet, you can find more info about the card here.




Motherboard - MSI K8T Master2-FAR
Processors - 2x AMD Opteron 240
Memory - 1GB (2x 512MB) Corsair XMS Platinum Low Latency (Twin Pack) ECC Registered PC3200
Hard Drives - Western Digital Special Edition 120GB 7200rpm w/8MB buffer (WD1200JB) | Maxtor 40GB 7200rpm w/2MB buffer
Optical Drive - MSI DVD+R/+RW Drive
Graphics - ATI Radeon 9800Pro 128MB DDR
Sound - Avance Logic (Now Realtek) ALC201A (Onboard Audio)
LAN - Broadcom BCM5705 Gigabit LAN (Onboard LAN controller)
Operating System - Windows XP Professional SP1
Monitor - NEC 1860NX 18.1" LCD
PSU - Antec 550W "True550"
Case - Chieftec AX-01SLD Aluminum Workstation Tower

morpheus777!!!!!!! you SUCK man! ;)

Or maybe I do because I don't have a SWEET opteron dually rig. Care to share some benchmarks and general performance differences between that rig and your dual Athlon MP??

One of these days I'm going to get a dual rig... one of these days. I'm thinking AFTER college though... :D





i just moved flat and had to build the desk, hence the tools etc...

i'm hoping to get modding on the boxes soon.

i'd like some input on how i can save some physical space. and, ideally, i'd like to cluster all three boxes. i may or may not depending on gf and $$$ be adding another 4 systems in the next month or two.

oh yeah, hi [H] - nice to be here :p

Dual Xeon 3.2. 3x18G 10K SCSI RAID0, 1x73.4GB 10K SCSI (all Seagate)
LSI U320-2 HBA, 2G Ram, Ti200 (easily oc'd to Ti500 levels).

It's even for sale in the Dallas area... depending on config... $2200-2600.



More pics here

cjcox said:
Dual Xeon 3.2. 3x18G 10K SCSI RAID0, 1x73.4GB 10K SCSI (all Seagate)
LSI U320-2 HBA, 2G Ram, Ti200 (easily oc'd to Ti500 levels).

It's even for sale in the Dallas area... depending on config... $2200-2600.



More pics here
Click to expand...
Link to case? :drool:

Uncut_Diamond said:
morpheus777!!!!!!! you SUCK man! ;)

Or maybe I do because I don't have a SWEET opteron dually rig. Care to share some benchmarks and general performance differences between that rig and your dual Athlon MP??
Click to expand...
Lol... I do suck don't I! :D

I shall get some benchies up as soon as I can (Im lazy :rolleyes: ).

Case is messy, so sue me. Opteron 244s.

2400+ MPs
1GB CAS2 REG ECC DDR
Tyan Tiger MPX
ATI 9800 AIW
Promise Fastrack S150TX4
2x WD Raptor 36GB 10k RPM SATA drives.
16x DVD and 52x CDR LiteOn drives
Audigy Platinum external
USB 2.0 card




Here's what it looked like when it had an AIW8500, 1800+ MPs and four 7200RPM 40GB maxtor drives hooked up to a Promise fastrack 100 TX4:
